Leaf Aptus-II Installation Guide

76 Chapter 8 – Mamiya RB
Connecting the Cables
Connecting the Camera-to-Back Sync Cable
1. Insert one end of the cable into the Mamiya Lens Flash socket.
2. Insert the opposite end of the cable into the Camera-to-Back Sync
socket on the adaptor plate.
Figure 6: Connecting a Camera-to-Back Sync cable to Leaf Aptus
Connecting the Flash Sync Cable
¾ Connect the Flash Sync cable to the Flash Sync connector on Leaf
Aptus.
Figure 7: Connecting a Flash Sync cable to the Leaf Aptus digital camera back
Note: You can use only external flash or strobe light with Leaf Aptus.
