Quick Installation Reference 49
Quick Installation Reference
1. Install the focusing screen mask.
2. Remove the protective cover from the digital camera back and mount
the back onto the camera body.
3. Connect the Camera-to-Back Sync cable between the camera lens and
Leaf Aptus
. If you are working in tethered mode, go straight to step 5.
4. Install the compact flash card. The installation is complete.
Working in tethered mode:
5. Install the Leaf Capture application from the CD and start the
application.
6. Connect the FireWire cable between the computer and Leaf Aptus.
After you connect the cable, the application automatically connects to
Leaf Aptus. When the connection is established, the LED indicator on
the digital camera back turns from orange to green.
Notes:
If you want to work with an external flash or strobe, connect the Flash Sync
cable between the camera and the flash or strobe unit.
For Hasselblad 553ELX, and 500EL/M, 503CW + winder users—To trigger
the camera from the computer, connect the Camera Control cable (not supplied
with the camera back) to the camera body and Leaf Aptus.
For Hasselblad 555 ELD users—When working in B-mode, the camera release
button must be in Film position.
