Leaf Aptus-II Installation Guide

38 Chapter 4 – Mamiya 645 AF-D
Removing the Leaf Digital Camera Back from the Camera Body
1. Place the camera on a steady, flat surface.
2. Turn the camera off.
3. Disconnect the FireWire cable.
4. Slide and press the Release button on to the left side.
Figure 8: Removing the Leaf Aptus digital camera back from a Mamiya 645
AF-D camera
5.
Tilt the camera back away from the camera body to remove it.
Release Button
