Leaf Aptus-II Installation Guide

82 Chapter 9 – Mamiya RZ67/RZ67ProII/ RZ67ProIID
Figure 1: Ports and sockets on the Leaf Aptus digital camera back
Figure 2: The Leaf Aptus digital camera back on a Mamiya RZ67 camera
FireWire port
[1]
Flash Sync socket
[2]
Camera-to-Back Sync socket
[3] Camera Control socket
[4]
1
2
3
4
