Leaf Aptus-II Installation Guide

72 Chapter 8 – Mamiya RB
Figure 1: Ports and sockets on the Leaf Aptus digital camera back
Figure 2: The Leaf Aptus digital camera back on a Mamiya RB camera
FireWire port
[1]
Flash Sync socket
[2]
3
Camera-to-Back Sync socket
[3] Camera Control socket
[4]
3
4
1
2
