Charging the Batteries 27
Figure 1: Connecting the hähnel MCL103 battery charger
3.
Insert the battery with contacts facing down and slide the battery fully
down into the contacts.
Once charging begins, an indicator light is turns on.
The indicator light begins to flash when the battery is almost charged.
Charging is complete when the indicator light turns off.
To charge the battery with the car lead:
1. Connect one end of the car lead cable to the hähnel MCL103 battery
charger.
2. Connect the car lead to the 12V car socket.
To remove the battery pack from the charger:
¾
Slide the battery off the charger.
Note: Do not leave the battery in the charger when the charger is not connected
to the power supply. This causes the battery to discharge.
