7-28 LeeBoy Model 8616 Conveyor Paver
Maintenance
Conveyor Drive Motor
Replacement
Removal
1. Remove hydraulic hoses from motor.
2. Remove four bolts holding hydraulic motor to slide
mount.
3. Slide drive motor out of slide mount.
Installation
1. Slide new or repaired drive motor into slide mount.
2. Secure with four bolts.
3. Reconnect hydraulic hoses to motor.
4. Check for leaks.
Cutoff Assembly Replacement
Removal
1. Remove clevis pin that connects the cutoff cylinder
to the cutoff.
2. Remove roll pin out of outer cutoff hinge.
3. Insert a 3/8” bolt in the end of the hinge pin to use to
remove pin.
4. Cutoff will slide down.
Installation
1. Clean area around cutoff hinge.
2. Align cutoff hinge.
3. Grease and insert hinge pin.
4. Insert roll pin into outer cutoff hinge.
5. Connect cylinder back to cutoff.
Auger And Inner Bearing
Replacement
1. Remove rear grating over auger assembly.
2. Run screed extension all the way out.
NOTE: This provides room to stand in behind auger
back to remove top portion of auger cover.
3. Remove two (2) nuts holding top cover on and pry
cover apart.
4. Clean asphalt build up from around cover.
NOTE: Heating asphalt may be required.
5. Remove bottom portion of cover by laying on
conveyor under engine [six (6) bolts].
6. Rotate augers so that master link is centered at
front.
7. Loosen auger chains by sliding auger motors down
from backside after loosening the two (2) bolts
securing mounting brackets.
8. Remove bottom clamps that hold auger bearings in.
NOTE: Roll pin is used to line up bearing grease hole
with the grease tting hole. If installed improperly,
no grease will get to bearing.
9. Remove auger end mounts so that augers can be
removed through opening in sides.
10. Remove augers and lay augers on the ground in
the same position as removed. This will help insure
proper installation of the new augers.
11. Check inner auger bearing and replace at this time
if faulty.
