2A 2B
PROPEL CONTROLLER
GROUND BLK 1
POWER RED 2
CAN1 + WHT 3
CAN1 - BLU 4
CAN1 SHIELD BLACK HEAT SHRINK 5
RT RUN/STOP SW WHT 6
RT NEUTRAL SW WHT 7
5VDC SENSOR POWER RED 8
SENSOR POWER GROUND BLK 9
LT RUN/STOP SW WHT 10
LT NEUTRAL SW WHT 11
GENERATOR ON SIGNAL BLU/RED 12
2 SPEED SW GRY/BLK 13
RIGHT RT JOYSTICK MV WHT 14
RIGHT LT JOYSTICK MV WHT 15
LEFT RT JOYSTICK MV WHT 16
LEFT LT JOYSTICK MV WHT 17
ENGINE HIGH TEMP SW BLU/WHT 18
ENGINE LOW OIL PRESS SW BRN 19
CAN2 + WHT 20
CAN2 - BLU 21
CAN2 SHIELD BLACK HEAT SHRINK 22
RT SONIC WHT 23
LT SONIC WHT 24
25
SCREED FLOAT SW GRN/YEL 26
HYD OIL TEMP PNK 27
FUEL LEVEL RED/WHT 28
COOLANT TEMP LT BLU 29
ENGINE OIL PSI BRN/YEL 30
BRAKE RELEASE BLU/WHT 31
BEACON RELAY BRN 32
WORK LIGHT RELAY BRN/YEL 33
VIBRATOR RELAY BLK/YEL 34
SCREED FLOAT RELAY GRN/YEL 35
GRADE AUTO RELAY BLU 36
RT TRACK REVERSE WHT 37
RT TRACK FORWARD WHT 38
LT TRACK REV WHT 39
LT TRACK FWD WHT 40
BACKUP ALARM BLU 41
2 SPEED VALVE GRY/BLK 42
ENGINE START ENABLE ORN/BLK 43
44
45
46
POWER RED 47
POWER RED 48
POWER RED 49
POWER RED 50
A
B
C
A
B
C
BACK UP
ALARM
LT FWD
LT REV
RT FWD
RT REV
PUMP NEUTRAL
1
2
HYD OIL TEMP SENSOR
CONNECTOR
#10 RING
TERMINAL
DELPHI PART NO
12162197
DT06-2S
DT06-2S
DT06-2S
DT06-2S
DT06-2S
2
1
1
1
1
1
2
2
2
2
TO SCREED
CONTROLLER
DT06-3S
C1
DT06-3S
TO ECM
6C
1A 1B
4D3E
GROUND BLK 1
POWER RED 2
3
4
5
LT CONV AUTO BLU/RED 6
LT CONV MAN BLU 7
5VDC SENSOR POWER RED 8
SENSOR POWER GROUND BLK 9
RT CONV AUTO GRN/WHT 10
RT CONV MAN GRN 11
LEFT AUGER/CONV OFF GRY 12
RIGHT AUGER CONV OFF GRY 13
LT CONV POT PUR 14
RT CONV POT BLU 15
LT AUGER POT YEL 16
RT AUGER POT ORN 17
LEFT AUGER OVERIDE ORN/WHT 18
RIGHT AUGER OVERIDE PNK 19
CAN1+ WHT 20
CAN1 - BLU 21
22
LT AUGER AUTO ORN/YEL 23
LT AUGER MAN ORN/WHT 24
RT AUGER AUTO PNK/BLK 25
RT AUGER MAN PNK 26
27
28
29
30
31
TRUCK HITCH IN YEL 32
TRUCK HITCH OUT WHT 33
WASH DOWN RELAY GRN/WHT 34
ENG SHUTDN RELAY ORN/BLK 35
36
RT AUGER VLV PNK/BLK 37
LT AUGER VLV ORN/YEL 38
RT CONV VLV GRN 39
LT CONV VLV BLU/RED 40
41
42
43
44
45
46
POWER RED 47
POWER RED 48
POWER RED 49
POWER RED 50
SCREED CONTROLLER
B
A
C
DT06-3S
C2
DT06-3S
A
C
B
TO PROPEL
