LeeBoy 8616 - Electronic Steering and Speed Control Box - Dual Joystick (Cont.)

5-12 LeeBoy Model 8616 Conveyor Paver
Component Location
Electronic Steering and Speed Control Box - Dual Joystick (Cont.)
RUN
STOP
LEFT
REVERSE
RIGHT
REVERSE
RIGHT
FORWARD
LEFT
FORWARD
14
5
2
3
Steering and Speed Control Box - Dual Joystick
Figure 5-4 (Continued)
1 - Left Steer Joystick
2 - Right Steer Joystick
3 - Run/Stop Switch
4 - Left Neutral Lock
5 - Right Neutral Lock
