5
LeeBoy Model 8616 Conveyor Paver 5-13
Component Location
Table 5-4. Electronic Steering and Speed Control Box - Dual Joystick (Continued)
ITEM NO. CONTROL NAME FUNCTION
3 Run/Stop Switch The Run/Stop switch controls stopping the machine and activating/deactivating
the operator control station. When the switch is set to the STOP position,
operator control station is deactivated, parking brake is applied, and machine
will not move. When switch is set to RUN, operator control station is activated,
parking brake is released, and machine resumes to previously set speed.
Operation Hazard! Never leave machine operator station
unattended with machine in gear and/or in motion. Operator station is
dened as the platform area within arms reach of active control steering
box. Operator must remain in operator’s station at all times when machine
is in gear and/or in motion. Before leaving machine operator station,
operator must return joysticks to neutral position and move RUN/STOP
switch to STOP position.
NOTE: T he paver can operate using only one operator station at a time. Paver
is typically operated from Left Operator Station (see Activating and
Deactivating Operator Control Station in Section 6).
NOTE: If the position of the joystick(s) has NOT changed from when the RUN/
STOP switch is moved to the STOP position and then later switched to
the RUN position, then paver will resume travel at the same speed of
travel when the switch is set to the RUN position. If the position of the
joystick(s) HAS changed from when the RUN/STOP switch is moved to
the STOP position then later switched to the RUN position, the paver
travel function will be temporarily disabled until joysticks are returned to
the NEUTRAL position.
Note: Set throttle to operating RPM’s before starting to move. Once throttle is
set and paver has been driven and stopped, machine will go back to idle
in approximately 10 seconds. Once joysticks are moved again, machine
will go back to operating RPMs.
4 Left Neutral Lock Locks the left lever in neutral. Pull up on the bottom of the knob to unlock.
5 Right Neutral Lock Locks the right lever in neutral. Pull up on the bottom of the knob to unlock.
