LeeBoy 8616 - Alphabetical Parts Index

10-74 LeeBoy Model 8616 Conveyor Paver
Illustrated Parts List (IPL)
Alphabetical Parts Index
Description Part Number Figure Number Item Number
30' To 40' Ski Assy 851585SRV 10-33 —
Actuator, Linear, 12V, Prop, 12mm 1006963-18 10-8 40
Air Cleaner Assy 38385 10-7 34
Aluminum Plug, 3/4” Coondulet 920238-5 10-31 -
Arm Extension, LH 930020SRV 10-5 14
Arm Extension, RH 930025SRV 10-5 15
Arm, Push Block 980787 10-4 8
Assembly, 8616, Control Box, With Dp610 1007229 10-17 -
Assembly, 8616, Control Box, With Dp610 1007229 10-16 1
Assembly, Conveyor Drive Adjustment 980106 10-6 9
Assembly, Conveyor Idler 1008919SRV 10-3 29
Assembly, Crown And Valley Front 1008668SRV 10-31 5
Assembly, Endgate, LH, HD 1006443SRV 10-26 1
Assembly, Endgate, RH, HD 1006560SRV 10-27 1
Assembly, Guide Bar, LH 1008730SRV 10-1 21
Assembly, Hydraulic Tank 1007083 10-9 1
Assembly, Inner Ext Mount, RH 1007099 10-25 14
Assembly, Inner, Ext Mount, LH 1007097 10-24 14
Assembly, Outer Ext Mount, LH 1007096 10-24 13
Assembly, Outer Ext Mount, RH 1007098 10-25 13
Assembly, Push Bar 980027 10-4 1
Assembly, Vandalism Cover 1007339 10-16 2
Assy ,Electric Heat Control 985138 10-30 2
Assy CB Bracket 983414-09 10-34 20
Assy Temp. Bail w/Sleeves 983414-10 10-34 1
Assy, Access Door ,LH 1007038 10-15 20
Assy, Access Door ,RH 1007039 10-15 18
Assy, AOA Adjuster 1006401 10-24 17
Assy, AOA Adjuster 1006401 10-25 17
Assy, Auger Motor Cover, 8515 981685 10-18 1
Assy, Auger To Back Brace 1007072 10-18 45
Assy, Beacon Light Post 989469SRV 10-15 -
Assy, Crown & Valley, Rear 980182 10-20 3
Assy, Crown & Valley, Rear 980182 10-31 6
Assy, Depth Screw, Endgate 1006453 10-26 7
Assy, Depth Screw, Endgate 1006453 10-27 7
Assy, Ext Heatbox 1006380SRV 10-24 1
Assy, Ext Heatbox 1006380SRV 10-25 1
