7-6 LeeBoy Model 8616 Conveyor Paver
Maintenance
General Information
Before performing any maintenance procedures on the
LeeBoy Model 8616 Conveyor Paver, read the following
safety information and review Safety in Section 2.
Tool Hazard! ALWAYS use tools
appropriate for the task at hand and use the correct
size tool for loosening or tightening screed parts.
Burn Hazard! ALWAYS handle hot
components with heat-resistant gloves.
This section gives the necessary procedures for routine
and general maintenance on the LeeBoy Model 8616
Conveyor Paver. Follow all the Maintenance Schedules
and Maintenance Procedures to maintain the paver in
top operating order.
Maintenance Schedule
General Information
The Maintenance Schedule lists the recommended time
intervals between LeeBoy Model 8616 Conveyor Paver
maintenance inspections and lubrication procedures.
The Lubrication Chart gives inspection and lubrication
information for the LeeBoy Model 8616 Conveyor Paver.
The “Hour” and “Periodic” time periods list most service
intervals. The maintenance schedule begins with 10-
hour, or daily, maintenance intervals and continues
through the 1000-hour, or annual, maintenance
schedule intervals.
NOTE: If the paver is operated more than 10 hours per
day, follow the “Hour” schedule. If the paver is
operated less than 10 hours per day, follow the
“Periodic” schedules, where they apply.
Preventive maintenance on the LeeBoy Model 8616
Conveyor Paver will provide years of trouble-free
operation. Adjustment can be performed in the eld with
ordinary hand tools. Engine preventive maintenance,
other than oil, air and fuel lter changes, is not covered
in this section. Refer to engine operator’s manual for
engine service information.
NOTE: For convenience there is an oil drain hose
located inside of the right-hand door on the
paver.
The changing of oil and cleaning of the
LeeBoy Model 8616 Conveyor Paver should
only be done in a designated area that can
contain the oil and chemicals involved in any
maintenance requirement. These by-products
should be discarded in accordance with
environmental regulations.
Do not substitute fasteners of any kind
unless the fasteners are equal in size and grade as
original equipment.
NOTE: When performing any routine maintenance such
as 50, 100, 250, and 500 hours, always include
previous routine maintenance hours in the higher
hourly schedule.
Preparing Paver for
Maintenance
When performing maintenance, perform the following
steps before leaving the operator’s position, unless the
maintenance procedure instructs otherwise.
1. Park the paver on a at even surface.
2. Lower all attachments to ground level.
3. Place joysticks in neutral.
4. Run engine at 1/2 speed (RPM) without load for 3 to
5 minutes.
5. Reduce engine speed (RPM) to slow idle.
6. Place ignition switch in the OFF position.
If maintenance must be performed with
engine running, do not leave paver unattended.
Paver Lubrication
Proper lubrication is necessary to maintain the LeeBoy
Model 8616 Conveyor Paver at top efciency. Refer to
the lubrication information in Table 7-2. Lubrication
Points Schedule. All lubrication points are shown in
(Figure 7-1 and Figure 7-2).
