LeeBoy 8616 - 8616 Conveyor Paver; Location of Operation Panels and Controls

5-2 LeeBoy Model 8616 Conveyor Paver
Component Location
Location of Operation Panels and Controls
8616 Conveyor Paver
3
2
6
7
8
4
5
1
9
8616 Conveyor Paver - View From Front
Figure 5-1
1 - Beacon Light
2 - Work Light
3 - Hopper
4 - Truck Rollers
5 - Conveyors
6 - Right Endgate
7 - Sonic Auger Sensor Bracket
8 - Spray Down Hose
9 - Diesel Fill
