LeeBoy Model 8616 Conveyor Paver 5-3
Component Location
Table 5-1. 8616 Conveyor Paver - View From Front
ITEM NO. CONTROL NAME FUNCTION
1 Beacon Light Used to alert surrounding vehicles and pedestrians of the LeeBoy Model
8616 Conveyor Paver location.
2 Work Light Used to illuminate path of the LeeBoy Model 8616 Conveyor Paver.
3 Hopper Receives and holds paving mix load while conveyors move material mix to
back of paver and screed.
4 Truck Rollers Rests against the back tires of the dump truck unloading paving mix into
hopper.
5 Conveyors Drag bars and chains help pull material mix from hopper area to auger and
screed. Right and Left sides can be controlled independently.
6 Right Endgate Used to create a clean edge in the paved base. Has vertical and angle
adjustments.
7 Sonic Auger Sensor
Bracket
Holds the Sonic Auger Sensor in proper position to maintain the proper
height of augered material. Connected to Sonic Auger Adjustment.
8 Spray Down Hose Used to spray cleaning solvent or release agent on parts of the paver in
preparation of paving.
9 Diesel Fill Used to fuel the LeeBoy Model 8616 Conveyor Paver.
