LeeBoy 8616 - 8616 Conveyor Paver (Continued)

5-4 LeeBoy Model 8616 Conveyor Paver
Component Location
8 - Left Endgate
9 - Left Screed Control Box
10 - Left Spray Down Hose
11- Manual Holder Box
12 - Left Steering and Speed Control Box
13 - Control Panel
8616 Conveyor Paver (Continued)
3
4
8
5
6
7
10
9
11
12
13
1
2
8616 Conveyor Paver - View From Back
Figure 5-2
1 - Battery Disconnect Switch
2 - Right Steering and Speed Control Box
3 - Right Screed Control Box
4 - Right Flight Screw
5 - Electric Heat Control Box
6 - Power Crown Control (Option)
7 - Left Flight Screw
