5
LeeBoy Model 8616 Conveyor Paver 5-5
Component Location
Table 5-2. 8616 Conveyor Paver - View From Back
ITEM NO. CONTROL NAME FUNCTION
1 Battery Disconnect
Switch
Disconnects all electrical power from the batteries to the rest of the paver.
Turn to the OFF position at the end of each day.
2 Right Steering and
Speed Control Box
Contains various steering and screed controls for the right side.
3 Right Screed Control
Box
Contains various screed controls for the right side.
4 Right Flight Screw This screw controls the depth of the asphalt for the right side.
5 Electric Heat Control
Box
Has a power switch (Figure 6-11,1), a START HEAT button (Figure 6-11,2),
and a heat cycle indicator light (Figure 6-11,3). Houses element breakers.
6 Power Crown Control
(Option)
Toggle switch up or down for power crown.
7 Left Flight Screw This screw controls the depth of the asphalt for the left side.
8 Left Endgate Used to create a clean edge in the paved base. Has vertical and angle
adjustments.
9 Left Screed Control Box Contains various screed controls for the left side.
10 Left Spray Down Hose Used to spray cleaning solvent or release agent on parts of the paver in
preparation of paving.
11 Manual Holder Box Contains the LeeBoy Model 8616 Conveyor Paver manual.
12 Left Steering and
Speed Control Box
Contains various steering and screed controls for the left side.
13 Control Panel Contains major paver systems and controls.
