2-6 LeeBoy Model 8616 Conveyor Paver
Safety
Safety Label Locations
If your LeeBoy Model 8616 Conveyor Paver has been
repainted, it is extremely important that all the decals
referring to CAUTION, WARNING, and DANGER be
replaced in their proper locations. The illustrations
on this page will aid you in determining the proper
locations; for additional help, you should refer to the
parts listing in the parts section of this manual and note
the description column.
A description of location is provided below for each
safety label. For additional instructions, contact your
dealer (see Contact Information in Section 3).
NOTE: It is the responsibility of the owner and operator
to make sure that all safety labels are readable
and located on paver as designated by LeeBoy.
Keep guidebar latched when transporting.
Keep all adjustments tight.
856441
CAUTION
Mantener la barra guía trabada durante el transporte.
Mantener todos los ajustes bien apretados.
PRECAUCION
Maintenir la barre de guidage verrouillée pendant le
transport. Maintenir tous les ajustements serrés.
ATTENTION
859773
856438
PINCH POINT
PUNTO DE APRIETE
POINT DE PINCEMENT
DANGER
PELIGRO
DANGER
DANGER
DANGER
PELIGRO
856437
PINCH POINT
PUNTO DE APRIETE
POINT DE PINCEMENT
8
5
9
7
89
WATCH YOUR STEP!
Failure to comply may result in minor or moderate injury.
CAUTION
SONIC AUGERS
859801
CAUTION
Ensure cord points
toward front.
856446
Hydraulic oil only
Keep clean
Huile hydraulique
seulement
Maintenir propre
PRECAUCION
ATTENTION
Aceite hidráulico solamente
Mantener limpio
CAUTION
859773
856438
PINCH POINT
PUNTO DE APRIETE
POINT DE PINCEMENT
DANGER
PELIGRO
DANGER
Aflojar los pernos del costado
cuando se ajusta la corona o valle.
Volver a apretar después de haber
alcanzado la corona deseada.
Desserrer les boulons sur le côté,
lors du réglage du bombement et du
creux.
Le resserrer une fois le bombement
désiré obtenu (couronne +).
CAUTION PRECAUCION ATTENTION
856483 REV 1
Loosen bolts on side when
adjusting crown and valley.
Retighten after reaching desired
crown.
8616 Conveyor Paver Safety Labels and Safety Label Locations
Figure 2-1
