LeeBoy 8616 - Electric Screed Operation Controls

5-14 LeeBoy Model 8616 Conveyor Paver
Component Location
Electric Screed Operation Controls
3
4
5
6
1
2
7
10
8
9
Screed Operation Controls
Figure 5-5
1 – Screed Operator Control Panel
2 – Flight Screw
3 – Electric Heat Control Box
4 – Crown and Valley Adjuster
5 – Screed Vibrator
6 – Extension Angle of Attack Screw
7 – Extension Vertical Adjustment Screws (2)
8 – Tilt Screw
9 – Depth Screw
10 – Sonic Auger Sensor Bracket
