LeeBoy Model 8616 Conveyor Paver 5-15
Component Location
Table 5-5. Electric Screed Operation Controls
ITEM NO. CONTROL NAME FUNCTION
1 Screed Operator
Control Panel
Contains controls for screed functions.
2 Flight Screw This screw controls the depth of the asphalt.
3 Electric Heat Control
Box
Has a Power switch (Figure 6-11,1), a Start Heat button (Figure 6-11,2), and
a Heat Cycle Indicator Light (Figure 6-11,3). Houses element breakers.
4 Crown and Valley
Adjuster
Adjusts for positive crown or negative valley in wear plate.
NOTE: Manual Crown and Valley Adjuster shown. Powered adjustment
option available.
5 Screed Vibrator Provides vibration to the screed frame for better mat compaction.
6 Extension Angle of
Attack Screw
Adjusts the back end of the extension wear plate. Tilt Rougher/Smoother.
7 Extension Vertical
Adjustment Screws (2)
Adjusts the front of the extension wearplate to provide the best mat. Up or
down and can level extension at wide widths.
8 Tilt Screw Used to adjust the tilt on the Endgate.
9 Depth Screw This controls the depth of the Endgate.
10 Sonic Auger Sensor
Bracket
Holds the Sonic Auger Sensor in proper position to maintain the proper
height of augered material. Connected to Sonic Auger Adjustment.
