LeeBoy 8616 - Page 235

10
LeeBoy Model 8616 Conveyor Paver 10-75
Illustrated Parts List (IPL)
Description Part Number Figure Number Item Number
Assy, Fuel Tank 1007084 10-9 5
Assy, New Style Seat Post,Short 988640SRV 10-6 13
Assy, Screed Arm Mnt, LH 1007024SRV 10-1 1
Assy, Screed Arm Mnt, RH 1007025SRV 10-1 —
Assy, Screed Arm, LH, Slp 1006437 10-28 2
Assy, Screed Arm, RH, Slp 1006438 10-29 2
Assy, Screed Ext, Lh, Slp 1006378SRV 10-24 6
Assy, Screed Ext, RH, Slp 1006379SRV 10-25 6
Assy, Screed, Citrus, Tank Elec 1006552SRV 10-30 1
Assy, Slide W/O Shafts 1006445 10-23 2
Assy, Slide W/Shafts, HD 1006416 10-23 1
Assy, Spacer, Auger Shaft 1007306 10-18 27
Assy, Spraydown Pump 984381 10-9 14
Assy, Turnbuckle W/Ratchet 983157 10-20 2
Assy, Upper Screed Cover, LH 1008757 10-20 19
Assy, Upper Screed Cover, RH 1008758 10-20 18
Assy, Vertical Lift Adj 1006390 10-24 16
Assy, Vertical Lift Adj 1006390 10-25 16
Assy, Vibrator, LH 1008449SRV 10-22 1
Assy, Vibrator, RH 1008448SRV 10-22 7
Auger End Mount Left 860051L 10-18 33
Auger End Mount Right 860051R 10-18 -
Auger Flight, LH, 12" 981700L 10-18 28
Auger Flight, RH, 12" 981700R 10-18 -
Auger Moun,LH 860051HDLSRV 10-18 -
Auger Moun,RH 860051HDRSRV 10-18 -
Axle, Guide Wheel 930045SRV 10-5 5
Ball Joint, 750, Male 1000947 10-24 18
Ball Joint, 750, Male 1000947 10-25 18
Bar, 25 X 15 X 36 985120 10-24 4
Bar, 25 X 15 X 36 985120 10-25 4
Bar, Adjustable Slide 851242 10-33 25
Bar, Adjustable Slide 851242
10-33 29
Bar, Cutoff Hinge 1007064 10-18 43
Bar, Element Hold Down 985121 10-20 9
Bar, Front Rubber Mount 980278 10-14 17
Bar, Idler Side Tapped 1006699 10-2 3
Bar, Push Bar Pin 856954 10-4 15
Bar, Rad Support, 8616 1006963-12 10-7 28
Bar, Roller Spacer, 1/4” 1007656 10-1 —
