LeeBoy Model 8616 Conveyor Paver 5-11
Component Location
Table 5-4. Electronic Steering and Speed Control Box - Dual Joystick
ITEM NO. CONTROL NAME FUNCTION
1 Left Steer Joystick
Lever controls the speed and direction of travel forward and reverse. Pushing
joystick forward moves machine forward. The farther forward, the faster the
speed. Pulling joystick backward moves machine backward. The farther
backward, the faster the speed. When joystick is centered, the machine is in
neutral and brake comes on. Pushing left joystick farther forward than right
joystick steers the paver to the right. The farther forward, the more the paver
turns.
Before moving paver, verify there are no people, obstacles or
other equipment in the path of the paver.
NOTE: Machine must be in neutral to start machine.
NOTE: You can only use one steering control module at a time. When steering
paver with control module the RUN/STOP Switch must be in RUN position
on the module in use and STOP position on the other module not in use.
2 Right Steer
Joystick
Lever controls the speed and direction of travel forward and reverse. Pushing joy-
stick forward moves machine forward. The farther forward the faster the speed.
Pulling joystick backward moves machine backward. The farther backward, the
faster the speed. When joystick is centered, the machine is in neutral and brake
comes on. Pushing right joystick farther forward than left joystick steers the paver
to the left. The farther forward, the more the paver turns.
Before moving paver, verify there are no people, obstacles or
other equipment in the path of the paver.
NOTE: Machine must be in neutral to start machine.
NOT E: You can only use one steering control module at a time. When steering
paver with control module, the RUN/STOP Switch must be in RUN position
on the module in use and STOP position on the other module not in use.
