LeeBoy Model 8616 Conveyor Paver 10-21
Illustrated Parts List (IPL)
Tanks Parts List
Item
No. Part Number Qty. Description Remarks
1 1007083 1 Assembly, Hydraulic Tank
2 982940 1
Filter Housing, Hyd.
3 100-6-16-20-5 4 CSHH, .375-16 x 1.25
4 300-6 4 Washer, Flat, .375
5 1007084 1 Assy, Fuel Tank
6 982033 1 Cap, Fuel
7 100-5-24-12-5F 4
CSHH, .313-24 x 0.75
8 300-5 4 Washer, Flat, .313
9 - 2 Battery, 12V, 1260CCA Buy Local
10 72313 1 Hold Down, Battery
11 100-8-13-140-5 2
CSHH, .500-13 X 9
12 300-8 4 Washer, Flat,
- 200-8-13-5 2
Nut, .500-13 Not Shown
13 500070 1 Gauge, Sight Level/Temp, Hyd Oil
14 984381 1 Assy, Spraydown Pump
- 1001542 A/R Pump, Spraydown
15 1006952 A/R Pump, Hyd, Tandem, H1 W/Edc
- 986519-01 A/R Coil, Control Bypass,H1 Pump
- 986519-02 A/R Nut, Coil Hold Down, H1 Pump
- 986519-03 A/R Repair Kit, Hyd Pump Shaft, H1
- 1006952-01 A/R
O-Ring, .103 X 3.737 FKM/Viton, 75D, SAE
16 1006956 A/R Pump, Hyd, L/S, 4.58 Cir, RH
17 620050 A/R Breather
