10
LeeBoy Model 8616 Conveyor Paver 10-69
Illustrated Parts List (IPL)
Generator Parts List
Item
No. Part Number Qty. Description Remarks
1 1008513 1 Generator, Hyd, Assy
2 1008513-02 1 Motor
3 1002454 1 Coupling Half, 3 Jaw, 24 mm
— 987894SRV 1 Coupling Assy, Motor To Generator, 28 mm Not Shown
4 985138-03 1 Power Cord, Bulkhead to Control Box
5 985825 1 Harness, Electric Heat, Gen to Bulkhead
— 986658 1 Capacitor, Generator, 40 uF Not Shown
— 1002148 1 Capacitor, Generator, 30 uF Not Shown
— 1002147 1 Capacitor, Generator, 25 uF Not Shown
— 1002146 1 Capacitor, Generator, 20 uF Not Shown
— 989259 1 Kit, Extension Harness Not Shown
