LeeBoy Model 8616 Conveyor Paver 10-77
Illustrated Parts List (IPL)
Description Part Number Figure Number Item Number
Bushing, 2.00 ID X 2.50 OD X 2.50 Idler 810070 10-18 32
Bushing, Arm Inner Roller 980441 10-28 4
Bushing, Arm Inner Roller 980441 10-29 4
Bushing, Bogie Roller 1006691 10-1 8
Bushing, Composite, Power Crown 1000960 10-31 -
Bushing, Fiber, 225 OD / 200 ID 1006417 10-23 3
Bushing, Screed Arm 980439 10-28 3
Bushing, Screed Arm 980439 10-29 3
Bushing, Track Idler/Truck Hitch 810070 10-5 12
Cable 1.063 851246 10-33 20
Cable Power, (+1) to Topcon 5, 8616 983414-17 10-34 5
Cable, Power, Ultrasonic 980550 10-26 11
Cable, Power, Ultrasonic 5 980550 10-27 11
Cap, Fuel 982033 10-9 6
Cap, Fuel Tank, Lockable 140030FL 10-30 11
Cap, Radiator, 13.5PSI, 2.25" Neck 1002184-04 10-7 2
Capacitor, Generator, 20 uF 1002146 10-32 —
Capacitor, Generator, 25 uF 1002147 10-32 —
Capacitor, Generator, 30 uF 1002148 10-32 —
Capacitor, Generator, 40 uF 986658 10-32 —
Cartridge,Check, 12Gpm 37113-04 10-12 —
Chain Assembly, Conveyor 1007052SRV 10-3 10
Chain Cover 981688 10-18 9
Chain Guard, Front 1006672 10-14 14
Chain Guard, Front, LH 1006673 10-3 2
Chain Guard, Front, RH 1006674 10-3 1
Chain Guard, Rear 1006675 10-3 3
Chain, 140mm, 40 Links 1007003-04 10-1 13
Chain, Conveyor, 87 Pitches w/Master, LH 1007052-02 10-3 35
Chain, Conveyor, 87 Pitches w/Master, RH 1007052-03 10-3 36
Chain, Proof Coil, .250 X 10 Link 858206 10-1 -
Chain, Roller, 50 X 18 r 1000958 10-31 9
Chain, Roller, 60H X 39 Pitches 1008047 10-20 4
Chain, Roller, 60H X 39 Pitches 1008047 10-31 8
Chain, Roller, 60H X 51 Pitch 985815 10-18 13
Chain, Roller, 80H X 60 And 1/2 Links 980220 10-6 4
Clamp Half, w/ Tapped Holes 852825 10-4 17
Clamp U-Bolt 981981 10-33 21
Clamp, Auger, 12" 1007269 10-18 25
Clamp, Element, Screed Ext 985123 10-24 3
