LeeBoy Model 8616 Conveyor Paver 10-81
Illustrated Parts List (IPL)
Description Part Number Figure Number Item Number
Decal, 8616, Wing, RH 1007679-03 10-15 -
Decal, Kit, 8616 Dec/Saf/Ops 1007679 10-15 -
Decal, Kit, HD Screed 1007677 10-15 -
Display, Dp610, 8616 1008316 10-17 5
Drag Bar 1007052-01 10-3 15
Drive Shaft, Front Axle Housing 980511 10-3 27
Drive Shaft, Rear Axle Housing 1007061 10-3 22
Dual-Joystick, Cont,Box, (+)One 1008904 10-16 8
Elbow, Rubber, 90, 3.50 X 3.00 ID 171170 10-8 36
Elec Steering Box Mount, 8500 855401L 10-16 6
Elec Steering Box Mount, 8500 855401R 10-16 7
Element, Heater, 46 1007276SRV 10-20 10
Element, Heater, Screed, 41" 1007278SRV 10-24 5
Element, Heater, Screed, 41" 1007278SRV 10-25 5
Enclosure, Control Panel 8616 W/Holes 1007228 10-17 1
Enclosure, Elec 3 Sw, Lwr Cont 1008240 10-28 1
Enclosure, Elec 3 Sw, Lwr Cont 1008241 10-29 1
End Cap, Auger Shaft 851647 10-18 35
Engine, Kubota, 99HP, Tier 3 1006963 10-8 43
Exhaust, Nipple, Kub 988673-16 10-7 22
Exhaust, Tip 90 986537-26 10-8 38
Fan Guard 986537-44 10-7 20
Fan Shroud 1006963-22 10-7 23
Fan, Engine, Kubota, V3800T 1006963-05 10-7 10
Filter Element, Fuel 982080-02 10-8 -
Filter Element, Hydraulic Charge 981917 10-10 6
Filter Element, Oil 982080-01 10-8 -
Filter Housing Assembly, Hydraulic 982940 10-10 9
Filter Housing, Hyd. 982940 10-9 2
FITT, 90 06MJ-08MP 34536 10-13 13
Flashing, Hopper Front 1007101 10-14 18
Flex Plate & Coupling, Sae C 14T 1006963-03 10-8 42
Flight Screw Assembly 1006427SRV 10-28 7
Flight Screw Assembly 1006427SRV 10-29 7
Flow Divider 983643-10 10-10 20
Flow Regulator, Cartridge 1006953-02 10-12 2
Flow Regulator, Cartridge 1006953-03 10-12 3
Flow Regulator, Cartridge 1006953-04 10-12 4
Fuse Block, 18 Gang, Atc 685060 10-17 2
Gasket, Condulet Box, 3/4” 920238-4 10-31 -
