LeeBoy Model 8616 Conveyor Paver 10-83
Illustrated Parts List (IPL)
Description Part Number Figure Number Item Number
Housing,Vibrator RH 982965R-1 10-22 8
Hyd. Motor, Conveyor Main 1008603 10-6 1
Hydraulic Cylinder 851436 10-14 1
Hydraulic Cylinder, Track Tension 980150 10-2 1
Hydraulic Filter Element 980350-01 10-10 8
Hydraulic Motor, Propulsion 980120 10-2 13
Hydraulic Tank 980174 10-10 1
Insert, 3-Jaw Coupling 280040 10-22 4
Isolator 986537-14 10-8 39
Isolator, Rad Lower Mnt 1001166-57 10-7 3
Key 982008-04 10-17 -
Key, Vandalism Locks 35560 10-15 -
Key, Vandalism Locks 35560 10-15 -
Kit, Extension Harness 989259 10-32 —
Kit, Grease Manifold, 8816 1003174 10-2 16
Kit, Hose Oil Drain Kubota 988169 10-8 -
Kit, Spraydown Pump and Strainer 1001428SRV 10-13 —
Knob, .25 Shaft 35049 10-17 15
Knob, .25 Shaft 35049 10-28 21
Knob, .25 Shaft 35049 10-29 21
Knob, Revolving Ball, M12 X 175 981574 10-26 8
Knob, Revolving Ball, M12 X 175 981574 10-27 8
Knob, Revolving Ball, M12 X 175 981574 10-28 8
Knob, Revolving Ball, M12 X 175 981574 10-29 8
Knob, Round Ball, 1.375 X .375-16 851156 10-28 -
Knob, Round Ball, 1.375 X .375-16 851156 10-29 -
Latch, Radiator Access Panel 160460 10-15 21
Lever Latch 980460 10-15 12
Lever Latch 980460 10-15 24
Lid, Access Door 1007088 10-15 11
Light, Led, 4.5” Worklight 1007968 10-15 26
Light, Led, 4.5” Worklight 1007968 10-28 25
Light, Led, 4.5” Worklight 1007968 10-29 25
Light, Red, Dash, 50 Hole 31983 10-30 3
Link, Master, Conveyor Chain 850070A 10-3 13
Link, w/Tab, Conveyor Chain 850080B 10-3 14
Lock Arm, Flight Screw 851373SRV 10-28 13
Lock Arm, Flight Screw 851373SRV 10-29 13
Locknut 95200879 10-28 10
Locknut 95200879 10-29 10
