LeeBoy Model 8616 Conveyor Paver 10-85
Illustrated Parts List (IPL)
Description Part Number Figure Number Item Number
Nut, Hex, 1.00-8 200-16-8-5 10-28 6
Nut, Hex, 1.00-8 200-16-8-5 10-29 6
Nut, Hex, 312-18 116-2 10-30 17
Nut, Hex, 375-16 116-3 10-24 28
Nut, Hex, 375-16 116-3 10-25 28
Nut, Hex, 375-16 116-3 10-28 16
Nut, Hex, 375-16 116-3 10-29 16
Nut, Hex, 437-14 116-4 10-24 25
Nut, Hex, 437-14 116-4 10-25 25
Nut, Hex, 437-14 116-4 10-26 23
Nut, Hex, 437-14 116-4 10-27 23
Nut, Hex, 500-13 116-5 10-20 28
Nut, Hex, 500-13 116-5 10-20 34
Nut, Hex, 500-13 116-5 10-21 5
Nut, Hex, 500-13 116-5 10-31 16
Nut, Hex, 500-13 116-5 10-31 19
Nut, Hex, 500-13 116-5 10-14 16
Nut, Hex, 625 116-7 10-14 9
Nut, Hex, 625-11 116-7 10-30 14
Nut, Lock, .500 143-5 10-33 19
Nut, Lock, .875-20 987396 10-26 16
Nut, Lock, .875-20 987396 10-27 16
Nut, Lock, 625-11 143-7 10-4 10
Nut, Poly Pad 1007003-10 10-1 20
Opt, 20Ft Ski 851584SRV 10-33 —
O-ring 982457 10-2 14
O-Ring, .103 X 3.737 FKM/Viton, 75D, SAE 1006952-01 10-9 -
Pad, molded with poly, 140mm chain 1007003-05 10-1 14
Pad, Poly, Bolt on Replacement 1007003-01 10-1 19
Pin, Chain 140mm 1007003-07 10-1 17
Pin, Clevis 980167SRV 10-2 2
Pin, Clevis 210060 10-5 21
Pin, Clevis, 1.00 X 3.25 W/1.5HD 240030 10-18 52
Pin, Cotter 81019 10-2 —
Pin, Cotter 80338 10-5 20
Pin, Cotter 81019 10-14 —
Pin, Cotter 80338 10-33 26
Pin, Cotter 80338 10-33 30
Pin, Cyl Mount 981661 10-20 8
Pin, Cylinder 980166 10-14 5
