LeeBoy 8616 - Page 247

10
LeeBoy Model 8616 Conveyor Paver 10-87
Illustrated Parts List (IPL)
Description Part Number Figure Number Item Number
Plug 987220-01 10-11 —
Plug 987220-02 10-11 —
Potentiometer, Rear Pump Speed, Plus1 1001822-05 10-17 14
Potentiometer, Rear Pump Speed, Plus1 1001822-05 10-28 -
Potentiometer, Rear Pump Speed, Plus1 1001822-05 10-29
Power Cord, Bulkhead to Control Box 985138-03 10-32 4
Pre-Filter, Fuel, Kub, T3, V3600TB 1001166-12 10-8 -
Pressure Switch (Flowjet Pump) 851448 10-13 11
Pull Pin Spring Loaded 1000835 10-16 5
Pull Pin Spring Loaded 1000835 10-16 12
Pump, Fuel, 12VDC, Kubota 8515 986537-39 10-7 6
Pump, Hyd, L/S, 4.58 Cir, RH 1006956 10-9 16
Pump, Hyd, Tandem, H1 W/Edc 1006952 10-9 15
Pump, Spraydown 1001542 10-9 -
Pump, Spraydown 1001542 10-13 2
Push Block Bracket 980786 10-4 18
Radiator Cover 987635 10-15 5
Radiator Isolator 986537-41 10-7 4
Radiator/Cooler Assy, Kub 988673-13 10-7 21
Rail, Dash Slide w/Holes 1007332 10-16 17
Rear Axle Housing 1007057 10-3 24
Relay, 12VDC, DPST, 25 Amp, N/O 985141 10-30 9
Relay, 12VDC, Spdt, 40 Amp, 5 Pin 36085 10-7 8
Relay, 12Vdc, Spdt, 40 Amp, 5 Pin 36085 10-17 4
Relay, Time Delay, Off,10 Amp 988231 10-30 7
Repair Kit, Hyd Pump Shaft, H1 986519-03 10-9 -
Rnd, 688 X 4350 CRS 854447SRV 10-24 11
Rnd, 688 X 4350 CRS 854447SRV 10-25 11
Rod, Guide Bar 1008728 10-1 -
Rod, Hinge Access Door 1007044 10-15 25
Rod, Threaded, 625-11 983589SRV 10-3 30
Roller 930040 10-5 10
Roller Assy, Push Bar, 24.00 Lg 980033 10-4 7
Roller, Conveyor Chain Idler (w/bearing) 850162 10-3 32
Rollpin 851118-1 10-3 12
Rubber, Hopper Wing Gusset 1007103 10-14 6
Screed Plate Asm, Main, 150-Wle 1008934 10-28 -
Screed Plate Asm, Main, 150-Wle 1008934 10-29 -
Screw, Wing, .375-16 X 1 120-6-24 10-16 9
Seal Kit 910170-01 10-18 -
