LeeBoy Model 8616 Conveyor Paver 5-7
Component Location
Table 5-3. Control Panel, Indicators and Gauges
ITEM NO. CONTROL NAME FUNCTION
1 Ignition Switch
Controls starting, stopping, and running of engine. Vertical position is OFF.
Turn right one notch for power. Red light will illuminate until engine cranks.
Far right is the START position. After engine starts, release switch, which will
automatically return to the POWER position. Turn left to preheat engine.
NOTE: Engine will not start unless joysticks are in NEUTRAL (Figure 5-4).
2 Display Unit Displays paver setup and calibration information, engine operating
information, and engine and paver system fault information.
3 E-Stop Button Press the E-Stop button to IMMEDIATELY DISABLE the paver engine and all
electronic functions. Turn clockwise to release E-Stop button.
The E-Stop button remains in a locked down position until
it is manually released. Unit will not restart until E-Stop is reset.
4 Right Tow
Thicker/Thinner Switch
Sets the thickness of the asphalt. Place switch in THICKER position for
thicker asphalt. Place switch in THINNER position for thinner asphalt.
5 2-Speed On/Off Switch Used to change machine speed. Place switch in OFF position for low speed.
Place the switch in ON for high speed position.
The ON position is only for traveling. Do not use the HIGH
speed position for paving.
When machine is powered on, the 2-Speed On/Off switch
will operate in its current position.
6 Horn Press and hold the button to sound the horn. The LED indicator on the
keypad will light when the button is pressed.
7 Screed Lift Raise/Float
Switch
Used to raise or oat the screed. Center position is hold. When released,
switch automatically returns to center position. Center holds the screed
position. To raise the screed, set switch to RAISE position. To oat the
screed, set switch to FLOAT position. (Switch should lock in FLOAT position.)
8 Right Auger Manual
Overide Off/Overide
Switch
Center is OFF position. Pull switch down to manually overide right auger.
9 Right Extension Switch Used to move the right extension in or out. Push switch to right arrow
( ) position to move right extension out. Push switch to left arrow ( )
position to move right extension in.
10 Left Auger Manual
Overide Off/Overide
Switch
Center is OFF position. Pull switch down to manually overide left auger.
