5
LeeBoy Model 8616 Conveyor Paver 5-9
Component Location
Table 5-3. Control Panel, Indicators and Gauges (Continued)
ITEM NO. CONTROL NAME FUNCTION
11 Hopper Wings Out/In
Switch
Used to move the hopper wings in and out. Push switch to OUT position to
open hopper wings. Push switch to IN position to close hopper wings.
12 Right Cutoff
Open/Close Switch
Used to open or close the right cutoff. Push switch to the OPEN position to
open right cutoff. Push switch to CLOSE position to close right cutoff.
13 Right Conveyor Dial Controls right conveyor speed when Right Conveyor Switch is set to AUTO
or MANUAL. Turning clockwise (CW) increases conveyor speed.
14 Right Conveyor
Auto/Off/Manual Switch
Selects automatic or manual override for right conveyor. Center is OFF
position. For automatic operation, set switch to AUTO position for conveyors
to work with sonics. MANUAL position controls conveyors with paddles.
15 Left Cutoff
Open/Close Switch
Used to open or close the left cutoff. Push switch to the OPEN position to
open left cutoff. Push switch to CLOSE position to close left cutoff.
16 Left Extension Switch Used to move the left extension in or out. Push switch to left arrow
( ) position to move left extension out. Push switch to right arrow ( )
position to move left extension in.
17 Left Conveyor
Auto/Off/Manual Switch
Selects automatic or manual override for left conveyor. Center is OFF posi-
tion. For automatic operation, set switch to AUTO position for conveyors to
work with sonics. MANUAL position controls conveyors with paddles.
18 Left Conveyor Dial Controls left conveyor speed when Left Conveyor Switch is set to AUTO or
MANUAL. Turning clockwise increases conveyor speed.
19 Left Tow Thick/Thinner
Switch
Sets the thickness of the asphalt. Place switch in THICKER position for
thicker asphalt. Place switch in THINNER position for thinner asphalt.
20 Control Panel Monitors and controls the major paver systems and controls.
