LeeBoy Model 8616 Conveyor Paver 5-17
Component Location
Table 5-6. Screed Operator Control Box
ITEM NO. CONTROL NAME FUNCTION
1 Left Slope Raise/Lower
UP position raises left slope. DOWN position lowers left slope. Center
position stops movement.
NOTE: Optional.
2 Left Auger Dial When Left Auger Auto/Off/Manual Switch is set to AUTO, the Left Auger Dial
controls pile height. Turning clockwise increases pile height. When Left
Auger Switch Auto/Off/Manual Switch is set to MANUAL, the Left Auger Dial
controls speed. Turning clockwise increases speed.
3 Left Auger Auto/Off/
Manual Switch
Selects automatic or manual override for left auger. Center is OFF position.
For automatic operation set switch to AUTO position. MANUAL position
provides override. Also cuts off conveyor in auto.
4 Left Extension In/Out IN position moves left extension in. OUT position moves left extension out.
Center position stops movement.
5 Left Tow Up/Down Tow UP adjusts left tow in the up direction. Tow DOWN adjusts left tow in the
down direction.
6 Left E-Stop Button Press the left E-Stop button to IMMEDIATELY DISABLE the paver engine
and all electronic functions. Turn clockwise to release E-Stop button.
The E-Stop button remains in a locked down position until
it is manually released. Unit will not restart until E-Stop is reset.
7 Horn Press button to sound horn.
8 Right Slope Raise/
Lower
UP position raises right slope. DOWN position lowers right slope. Center
position stops movement.
NOTE: Optional.
9 Right Tow Up/Down Tow UP adjusts right tow in the up direction. Tow DOWN adjusts right tow in
the down direction.
10 Right Extension In/Out IN position moves right extension in. OUT position moves right extension out.
Center position stops movement.
11 Right Auger Auto/Off/
Manual Switch
Selects automatic or manual override for right auger. Center is OFF posi-
tion. For automatic operation set switch to AUTO position. MANUAL position
provides override. Also cuts off conveyor in auto.
12 Right Auger Dial When Right Auger Auto/Off/Manual Switch is set to AUTO, the Right Auger
Dial controls pile height. Turning clockwise increases pile height. When
Right Auger Switch Auto/Off/Manual Switch is set to MANUAL, the Right
Auger Dial controls speed. Turning clockwise increases speed.
13 Right E-Stop Button Press the right E-Stop button to IMMEDIATELY DISABLE the paver engine
and all electronic functions. Turn clockwise to release E-Stop button
The E-Stop button remains in a locked down position until
it is manually released. Unit will not restart until E-Stop is reset.
14 Horn Press button to sound horn.
