ITEM
NO.
COMPONENT NAME FUNCTION
7 Park Brake Light Illuminates when the park brake is engaged.
8 Cab Fan Turns cab fan on and off. Turn button right to activate.
9 Horn Press button to sound horn.
10 Water System Turns the water system on and off.
11 Beacon Light Turns beacon light on and off.
12 Front Work Lights Turns front work lights on and off.
13 Rear Work Lights Turns rear work lights on and off.
14 Hazard Lights Flashing hazard lights to alert trafc.
15
Transmission Selector
Lever / Joystick
Pushing joystick forward increases machine speed while pulling joystick
backward slows machine speed. Also features controls for oating and
swinging brush left or right.
16
Brush Swing Left (Side
Shift Option)
If equipped with this option, controls side shift brush swing to the left.
17 Brush Left Controls brush swing to the left.
18 Brush Lift/Float Controls brush lift and oat.
19 Brush Swing Right Controls brush swing to the right.
20
Brush Swing Right (Side
Shift Option)
If equipped with this option, controls side shift brush swing to the right.
21 Brush Down Pressure
Controls the brush pressure on the work surface. Turn clockwise to
increase pressure and counterclockwise to decrease pressure.
22 Cup Holder The cup holder is an added convenience for the operator.
23 Ignition Switch
Turn key clockwise to start the engine. Turn key counterclockwise to shut
off the engine. Transmission Selector MUST be in the NEUTRAL position
to start. Features a Neutral Start system to prevent operation of the engine
starter when the transmission is not in neutral.
24 12-Volt Outlet 12-volt electrical outlet.
25 Two Speed Switch
High Gear: Full displacement that allows higher transport speeds. Push
switch left for High Gear.
Low Gear: Partial displacement providing greater torque and lower speeds.
Push switch right for Low Gear.
NOTE: Use ONLY low gear while sweeping.
26 Brush Speed Dial
Turn dial left to increase brush speed. Turn dial right to decrease brush
speed based on engine RPMs.
27 Emergency Stop
This button breaks power to the ignition switch. Push button to lock. Twist
button to unlock.
28 Signal Lights Push button left for left turn signal. Push button right for right turn signal.
29 Brush Drive Engage Lever
Turns brush rotation on and off. Push lever forward to engage. Pull lever
backward to reverse brush rotation.
30 Park Brake Lever Raise to engage park brake. Lower lever to release park brake.
33
Component Location
LB Performance CB95 Broom 3-7
