Adjust SeatAdjust Seat
The operator seat suspension provides comfort by
absorbing some of the machine movements during
operation. It can also be adjusted for individual comfort.
(Figure 4-5)
Always make seat and seat belt adjustments BEFORE
driving the sweeper. The seat belt is designed for
safe operator retention if the machine is involved in an
accident or roller-over.
• Use the suspension adjustment knob to set the
suspension for operator weight. Rotate knob to
increase or decrease setting as shown on the knob
face.
• Use the seat position adjustment lever to move the
seat forward or backward. Pull up on the lever to
adjust and release to lock into place.
Seat Position
Adjustment Lever
Suspension
Adjustment Knob
Figure 4-5. Seat Adjustment
Adjust Steering ConsoleAdjust Steering Console
Figure 4-6. Tilt Lock Toe Pedal
The steering wheel steers like any other steering wheel.
Steering takes priority over brush operations (rotation,
lift and swing) for operator safety.
You can adjust the steering column using the tilt lock
pedal at the bottom of the steering column. (Figure 4-6)
To adjust, simply depress the pedal with your foot
and tilt the steering column forward or backward to a
comfortable position, then release the tilt lock pedal and
it locks into place.
Cab AC/HeatCab AC/Heat
For added operator comfort, an air conditioning and
heater option is also available. (Figure 4-7)
Heat
Fan
A/C
Figure 4-7. Cab AC/Heat
44
Operation
LB Performance CB95 Broom 4-7
