LeeBoy LB Performance CB95 - Specification Charts

SPECIFICATION CHARTS
The specications provided in this section include the
machine weights, dimensions, performance, and torque
values for both metric and standard inch fasteners.
8’ 5”
15’ 6”
11’ 8”
7’ 9”
5’ 11”
Table 2-1. Machine Dimensions
ITEM SPECIFICATION
Overall Length 15 ft 6 in
Overall Height (with Roll-Over Protection System
[ROPS])
8 ft 5 in
Overall Height (with ROPS and Beacon Light) 9 ft 5 in
Overall Width 7 ft 9 in
Tread Width (Front and Rear) 5 ft 11 in
Overall Weight (without Water) 5250 lb
Wheelbase 11 ft 8 in
Outside Turning Radius 18 ft 9 in
Ground Clearance 8.75 in
Cab
Includes: 12-Volt, Variable Speed Rear Defroster Fan; 12-Volt,
2-Speed Windshield Wiper; Windshield Washer (Front and
Rear).
Climate-Control Cab Options: 16,000 BTU/Hr (4690 Watt) Air
Conditioning; 28,000 BTU/Hr (8206 Watt) Heater
Replace original equipment only with
components approved by LB Performance.
LB Performance CB95 Broom
2-4
Information and Specications
