Strike-Off BladeStrike-Off Blade
You will need an assistant to attach and remove the
optional strike-off blade attachment to the front of the
broom. (Figure 4-26)
1. Park the broom on a level surface, turn off the
engine and engage the parking brake.
2. Clean the blade-mounting front fender thoroughly
before attaching blade.
3. Support the blade with jack stands in front of the
broom front fender.
Cotter Pins
Figure 4-26. Blade Attachment Option
Figure 4-27. Telescoping Steering and Transmission
Foot Pedal
Telescoping Steering Telescoping Steering
The optional telescoping steering column coupled with
the standard tilt column adds maximum cab comfort on
the job. (Figure 4-27) The telescoping steering column
option allows you to tilt the steering column and adjust
your steering wheel for a more comfortable ride.
Magnetic Cup Magnetic Cup
HolderHolder
Magnetic cup holders can
be purchased for use with
your road widener (and
other machines in your
eet). (Figure 4-28)
See your authorized dealer
for details. Ask for Part
Number 1020521.
Figure 4-28. Magnetic
Cup Holder
Operation
LB Performance CB95 Broom4-18
