X75HD Installation and Operation Manual 9
Chapter 1: Introduction
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute.
Rear Panel Description
Figure 1-3 illustrates a typical rear panel with all module options
installed. Figure 1-4 provides a graphical overview of the rear panel
connector placement.
Figure 1-3. X75HD Rear Panel
Figure 1-4. Overview of Connector Placement
For more information on back panel connections, see “Chapter 4:
System Installation and Connections”.
Optional audio
SDTV video
HDTV video
Optional analog
video input
Multi I/O DVI
RS-232/
422
Dual
Ethernet
