LEM NORMA 5000 User Manual

Connection to Circuits
Power Analyzer NORMA 4000, NORMA 5000 15
EO1111G REV G
5.3.3 With voltage and current transducer
Fehler! AutoText-Eintrag nicht definiert.
Risk of damage to transducer, due to overload!
 Check rating of transducer.
Note
When using transducers, please note that transducer errors limit
the measuring bandwidth and reduce the intrinsic uncertainty.
Fehler! AutoText-Eintrag nicht definiert.
Danger! Risk of electrocution!
Risk of injury when touching connections, internal circuits and
measuring devices that are not earthed.
 Always adhere to the instructions regarding the sequence of
connection (see page 12).
S
1
S
2
an
AN
P
1
P
2
U I
N
L1
max. 10 m
1
HI
CURRENT
LO
10 A max
PROBE
EXT.SHUNT
10 V max
HI
VOLTAGE
LO
1000 V max
2
HI
CURRENT
LO
10 A max
PROBE
EXT.SHUNT
10 V max
HI
VOLTAGE
LO
1000 V max
3
ALL INPUTS MAX 1000V CATII TO
