Design and functions
10 Power Analyzer NORMA 4000, NORMA 5000
EO1111G REV G
The assignment of the function keys varies, depending on the
display or menu you have selected.
Name Function
Default
Scale axes automatically
DELETE
Delete configuration
Detail
View details of a measured value
Freq
Set frequency analysis filter
Info…
View system information and version number of
unit firmware
LCD -
Reduce brightness of display
LCD +
Increase brightness of display
lin/log
View linear/logarithmic scale
LOAD
Load configuration
mode
View table with harmonics
Offset
Adjust zero (with cursor keys)
rms/h01
View rms values or H01 fundamental
SAVE
Save configuration
Scale
Adjust scales of axes (with cursor keys)
scroll
Scroll through display
Set all
Adopt configuration or set value for all channels
tab/gra
View measured values in table/graph
U/I
Switch between voltage channel configuration
and current channel configuration (in General
Setup)
zoom
Adjust scales of axes (with cursor keys)
∫
View electrical work reference power or
recuperated power
∫ Clear
Set electrical work integration to zero
∫ Start
Start electrical work integration
∫ Stop
Stop electrical work integration
3.3 Functions
The power analyzer allows for the analysis of currents from DC to
several MHz. Voltage values up to 1000 V and currents up to 20 A
are measured accurately, and the respective real, idle and
apparent power is calculated. The limit of error is between 0.1%
and 0.3%, depending on the model. For DC and AC up to a few
MHz, it is not affected by the wave shape, frequency or phase
position. The measuring range can be extended by connecting
shunts or clamps. When extending the range using third-party
shunts or clamp the extra errors due to these devices should be
considered. The device caters for simultaneous measuring in up to
6 channels.
Overview of
function keys
