LEM NORMA 5000 - With Voltage and Current Transducer

Connection to Circuits
18 Power Analyzer NORMA 4000, NORMA 5000
EO1111G REV G
5.4.3 With voltage and current transducer
Fehler! AutoText-Eintrag nicht definiert.
Risk of damage to transducer due to overload!
 Check rating of transducer.
Note
When using transducers, please note that transducer errors limit
the measuring bandwidth and reduce the intrinsic uncertainty.
Fehler! AutoText-Eintrag nicht definiert.
Danger! Risk of electrocution!
Risk of injury when touching connections, internal circuits and
measuring devices that are not earthed.
 Always adhere to the instructions regarding the sequence of
connection (see page 12).
1
HI
CURRENT
LO
10 A max
PROBE
EXT.SHUNT
10 V max
HI
VOLTAGE
LO
1000 V max
2
HI
CURRENT
LO
10 A max
PROBE
EXT.SHUNT
10 V max
HI
VOLTAGE
LO
1000 V max
3
ALL INPUTS MAX 1000V CATII TO
max. 10 m
L2
L1
L3
CBA
abc
P1
L1
S1
L1
P2
L1
S2
L1
P1
L3
S1
L3
P2
L3
S2
L3
I
3
I
1
