PI1 Process Interface (optional)
64 Power Analyzer NORMA 4000, NORMA 5000
EO1111G REV G
9.5.3 4 outputs (analog)
Output voltage max. ± 10.3 V; max. load 5 mA,
short-circuit protected, shared LO
connection to ground potential
Allowable external voltage max. 50 Vrms at HI input
Additional error ± (0.15 % of AVG + 0.05 % of FV),
final value FV = 10 V
Temperature coefficient < 0.2 x fault limit/K
Output rate corresponds to current average
time
Resolution approx. ± 8000 counts for ± 10 V, 1
count ≈ 1.25 mV
Rise time 10...90 %: approx. 10 ms
to ± 0.2 %: 25 ms Response time
to ± 1.0 %: approx. 20 ms
