7 Configuration
Prior to measuring, you must configure the default settings, adjust
channels, measuring ranges and times and synchronise current
and voltage sources.
If you wish to reapply certain settings at a later stage, you must
save the configuration. You have the option to save up to 15 user-
defined configurations, which are automatically assigned the
names 10:USER to 24:USER.
When first switching on the analyzer, factory configuration 1:W3 is
used. This configuration is suitable for measurements with
fundamentals below 100 Hz (average time 300 ms,
synchronisation source U1, low-pass filter 100 Hz).
Note
You have the option to modify the settings of configuration 1:W3. If
you wish to save the new settings, you must do this in a new
configuration. Default configuration 1:W3 cannot be overwritten.
You may save new settings in the process or at the end of the
configuration procedure. Settings that have not been saved are lost
when the device is switched off or when a different configuration is
loaded.
- modify configuration 1:W3 loaded upon startup of the
device,
- load an existing configuration,
- create a new configuration,
- delete or modify an existing configuration.
The power analyser features the following configuration menus:
Configuration menu Description
General Setup
Interfaces, printer output
Timing & Sync Setup
Average time and synchronisation
Clock Setup
Date and time
Current Channel Setup
Current channels 1 … 6
Voltage Channel Setup
Voltage channels 1 … 6
Motor / Generator Setup
PI1 process interface inputs
Analog Output Setup
PI1 process interface outputs
Integration Setup
Integration function / energy
To set up a configuration, complete the following steps:
- Call up General Setup
- Configure current and voltage channels
- Configure average time and synchronisationConfigure data
transfer to printer and PCSave configuration
For instructions on how to configure the PI1 process interface,
please refer to chapter 9: "PI1 Process Interface (optional)", page
57
For instructions on how to delete a configuration, please refer to
chapter 7.10 ”Delete configuration", page 37.
Configuration
1:W3
You may ...
5 steps
