LEM NORMA 5000 - Comparing Measured Values

Measuring process
Power Analyzer NORMA 4000, NORMA 5000 41
EO1111G REV G
 Press function key Detail again.
Details regarding the current values are displayed. The
equivalent parameters to those shown above for voltage are
displayed.
 Press function key Detail again.
Details regarding the power values, e.g. for channel 2, are
shown.
Display Description
P
2
Power
P
c2
Corrected power
Z
2
Apparent impedance
φ
2
Angle between U2 and I2
 Press function key Detail again.
Details regarding the measured values for phase-to-phase
voltage are displayed.
 To return to the measured values for channel 2, press function
key Detail again.
