6.Slidethenewopticaldriveintothedrivebayfromthefrontuntilitsnapsintoposition.
Note:Youdonotneedtoremovethefrontbezelwhenreplacinganopticaldrive.However,ifyouare
addingasecondaryopticaldriveintheupperopticaldrivebay,youneedtoremovethefrontbezelrst
andthengainaccesstotheprotectiveshieldstoremovethem.Thefollowingillustrationshowsonlythe
situationinwhichthefrontbezelhasnotbeenremoved.
Figure56.Installingtheopticaldrive
7.Connecttheappropriatepowercable1andthesignalcable2totherearofthenewopticaldrive.
Figure57.Connectingcablestotherearoftheopticaldrive
8.Ifnecessary,connecttheotherendofthesignalcabletotheappropriateSATAconnectoronthesystem
board.See“Systemboardcomponents”onpage42.
9.Reinstallthefrontbezelifyouhaveremovedit.See“Removingandreinstallingthefrontbezel”on
page87.
10.Dooneofthefollowing:
