Thistopicprovidesinstructionsonhowtoreplaceahot-swapredundantpowersupplymodule.
Thistopicappliesonlytoservermodelsthatcomewithhot-swapredundantpowersupplymodule(s).For
eachhot-swapredundantpowersupplymodule,theremightbeoneortwostatusLEDsonthepower
supplymodulenearthepowercordconnector.WhenthegreenLEDislit,itindicatesthatthehot-swap
redundantpowersupplymoduleisworkingproperly.WhentheredLEDislit,itindicatesthatthehot-swap
redundantpowersupplymodulehasfailed.
Thehot-swapredundantpowersupplymoduleshelpyouavoidsignicantinterruptiontotheoperationof
thesystemwhenapowersupplymodulefailsandyoucanreplaceahot-swapredundantpowersupply
modulewithoutturningofftheserver.
Note:TomaintaintheEMIintegrityandcoolingoftheserver,installanewhot-swapredundantpower
supplymoduleassoonasyouremovethefailingoneorcovertheotherbaywithashieldifyoujustuse
onemoduletoprovidepower.
CAUTION:
Hazardousmovingparts.Keepngersandotherbodypartsaway.
CAUTION:
Neverremovethecoveronapowersupplyoranypartthathasthefollowinglabelattached.
Hazardousvoltage,current,andenergylevelsarepresentinsideanycomponentthathasthislabel
attached.Therearenoserviceablepartsinsidethesecomponents.Ifyoususpectaproblemwith
oneoftheseparts,contactaservicetechnician.
Beforeyoubegin,printalltherelatedinstructionsorensurethatyoucanviewthePDFversiononanother
computerforreference.
Notes:
1.Yourhot-swapredundantpowersupplymodulemightlookslightlydifferentfromtheillustrationsin
thistopic.
2.Useanydocumentationthatcomeswiththenewhot-swapredundantpowersupplymoduleandfollow
thoseinstructionsinadditiontotheinstructionsinthistopic.
Toreplaceahot-swapredundantpowersupplymodule,dothefollowing:
