The compact system
7
Mechanical installation
7.3
l
7.3-1
EDSPM-TXXX-3.0-04/2004
7.3 The compact system
Mounting dimensions and other dimensions
34 mm
101 mm
48 mm
34 mm
27 mm
35 mm
76 mm
EPM-T830
34 mm
152 mm
76 mm
69 mm
34 mm
48 mm
EPM-T833
01
01
34 mm
101 mm
76 mm
69 mm
34 mm
48 mm
EPM-T831
01
34 mm
152 mm
76 mm
69 mm
34 mm
48 mm
EPM-T832
01
30 mm
7.5/15 mm
epm-t054
Fig. 7.3-1 Module dimensions of the compact system
