Index table
14
Appendix
14.2
l
14.2-8
EDSPM-TXXX-3.0-04/2004
Index ImportantPossible settingsName
SelectionLenze
I1807
h
Index is only a vailable in the modular
system
E 9.4-3
1 COB-ID used by
TxPDO 8
1216 385 {1} 2047 Defining the individual identifie rs for
process da ta object 8
2 Transmisson type 255 0 {1} 255 Defining the transmission mode
1 Sync-controlled transmit The output data are a ccepted on sync
telegram transmission.
2 ... 240 n-sync-controlled transmission The output data are a ccepted after
transmission of the set number (1 ... 240)
of sync telegrams.
254 Time-controlled transmission Only if a cycle time is set in I180x
h
,
subindex 5
255 Event-controlled transmission
255 Event-controlled transmission with cyclic
overlapping
Only if a cycle time is set in I180x
h
,
subindex 5
3 Inhibit time 0 0 {1 ms} 65535 Inhibit time
5 Event time 0 {1 ms} 65535 Cycle time
I1808
h
Index is only a vailable in the modular
system
E 9.4-3
1 COB-ID used by
TxPDO 9
1728 385 {1} 2047 Defining the individual identifie rs for
process da ta object 9
2 Transmisson type 255 0 {1} 255 Defining the transmission mode
1 Sync-controlled transmit The output data are a ccepted on sync
telegram transmission.
2 ... 240 n-sync-controlled transmission The output data are a ccepted after
transmission of the set number (1 ... 240)
of sync telegrams.
254 Time-controlled transmission Only if a cycle time is set in I180x
h
,
subindex 5
255 Event-controlled transmission
255 Event-controlled transmission with cyclic
overlapping
Only if a cycle time is set in I180x
h
,
subindex 5
3 Inhibit time 0 0 {1 ms} 65535 Inhibit time
5 Event time 0 {1 ms} 65535 Cycle time
I1809
h
Index is only a vailable in the modular
system
E 9.4-3
1 COB-ID used by
TxPDO 10
1984 385 {1} 2047 Defining the individual identifie rs for
process da ta object 10
2 Transmission mode 255 0 {1} 255 Defining the transmission mode
1 Sync-controlled transmission The output data are accepted on sync
telegram transmission.
2 ... 240 n-sync-controlled transmission The output data are a ccepted after
transmission of the set number (1 ... 240)
of sync telegrams.
254 Time-controlled transmission Only if a cycle time is set in I180x
h
,
subindex 5
255 Event-controlled transmission
255 Event-controlled transmission with cyclic
overlapping
Only if a cycle time is set in I180x
h
,
subindex 5
3 Inhibit time 0 0 {1 ms} 65535 Inhibit time
5 Event time 0 {1 ms} 65535 Cycle time
