Index table
14
Appendix
14.2
l
14.2-7
EDSPM-TXXX-3.0-04/2004
Index ImportantPossible settingsName
SelectionLenze
I1804
h
Index is only a vailable in the modular
system
E 9.4-3
1 COB-ID used by
TxPDO 5
448 385 {1} 2047 Defining the individual identifie rs for
process da ta object 5
2 Transmission type 255 0 {1} 255 Defining the transmission mode
1 Sync-controlled transmit The output data are a ccepted on sync
telegram transmission.
2 ... 240 n-sync-controlled transmission The output data are a ccepted after
transmission of the set number (1 ... 240)
of sync telegrams.
254 Time-controlled transmission Only if a cycle time is set in I180x
h
,
subindex 5
255 Event-controlled transmission
255 Event-controlled transmission with cyclic
overlapping
Only if a cycle time is set in I180x
h
,
subindex 5
3 Inhibit time 0 0 {1 ms} 65535 Inhibit time
5 Event time 0 {1 ms} 65535 Cycle time
I1805
h
Index is only a vailable in the modular
system
E 9.4-3
1 COB-ID used by
TxPDO 6
704 385 {1} 2047 Defining the individual identifie rs for
process da ta object 6
2 Transmission type 255 0 {1} 255 Defining the transmission mode
1 Sync-controlled transmit The output data are a ccepted on sync
telegram transmission.
2 ... 240 n-sync-controlled transmission The output data are a ccepted after
transmission of the set number (1 ... 240)
of sync telegrams.
254 Time-controlled transmission Only if a cycle time is set in I180x
h
,
subindex 5
255 Event-controlled transmission
255 Event-controlled transmission with cyclic
overlapping
Only if a cycle time is set in I180x
h
,
subindex 5
3 Inhibit time 0 0 {1 ms} 65535 Inhibit time
5 Event time 0 {1 ms} 65535 Cycle time
I1806
h
Index is only a vailable in the modular
system
E 9.4-3
1 COB-ID used by
TxPDO 7
960 385 {1} 2047 Defining the individual identifie rs for
process da ta object 7
2 Transmisson type 255 0 {1} 255 Defining the transmission mode
1 Sync-controlled transmit The output data are a ccepted on sync
telegram transmission.
2 ... 240 n-sync-controlled transmission The output data are a ccepted after
transmission of the set number (1 ... 240)
of sync telegrams.
254 Time-controlled transmission Only if a cycle time is set in I180x
h
,
subindex 5
255 Event-controlled transmission
255 Event-controlled transmission with cyclic
overlapping
Only if a cycle time is set in I180x
h
,
subindex 5
3 Inhibit time 0 0 {1 ms} 65535 Inhibit time
5 Event time 0 {1 ms} 65535 Cycle time
