Index ImportantPossible settingsName
SelectionLenze
I1801
h
Index is only a vailable in the modular
system
E 9.4-3
1 COB-ID used by
TxPDO 2
639 385 {1} 2047 Defining the individual identifie rs for
process da ta object 2
2 Transmisson type 255 0 {1} 65535 Defining the transmission mode
0 Sync-controlled transmit The output data are a ccepted on sync
telegram transmission.
1 ... 240 n-sync-controlled transmission The output data are a ccepted after
transmission of the set number (1 ... 240)
of sync telegrams.
254 Time-controlled transmission Only if a cycle time is set in I180x
h
,
subindex 5
255 Event-controlled transmission
255 Event-controlled transmission with cyclic
overlapping
Only if a cycle time is set in I180x
h
,
subindex 5
3 Inhibit time 0 0 {1 ms} 65535 Inhibit time
5 Event time 0 {1 ms} 65535 Cycle time
I1802
h
Index is only a vailable in the modular
system
E 9.4-3
1 COB-ID used by
TxPDO 3
384 385 {1} 2047 Defining the individual identifie rs for
process da ta object 3
2 Transmisson type 255 0 {1} 255 Defining the transmission mode
1 Sync-controlled transmit The output data are a ccepted on sync
telegram transmission.
2 ... 240 n-sync-controlled transmission The output data are a ccepted after
transmission of the set number (1 ... 240)
of sync telegrams.
254 Time-controlled transmission Only if a cycle time is set in I180x
h
,
subindex 5
255 Event-controlled transmission
255 Event-controlled transmission with cyclic
overlapping
Only if a cycle time is set in I180x
h
,
subindex 5
3 Inhibit time 0 0 {1 ms} 65535 Inhibit time
5 Event time 0 {1 ms} 65535 Cycle time
I1803
h
Index is only a vailable in the modular
system
E 9.4-3
1 COB-ID used by
TxPDO 4
896 385 {1} 2047 Defining the individual identifie rs for
process da ta object 4
2 Transmisson type 255 0 {1} 255 Defining the transmission mode
1 Sync-controlled transmit The output data are a ccepted on sync
telegram transmission.
2 ... 240 n-sync-controlled transmission The output data are a ccepted after
transmission of the set number (1 ... 240)
of sync telegrams.
254 Time-controlled transmission Only if a cycle time is set in I180x
h
,
subindex 5
255 Event-controlled transmission
255 Event-controlled transmission with cyclic
overlapping
Only if a cycle time is set in I180x
h
,
subindex 5
3 Inhibit time 0 0 {1 ms} 65535 Inhibit time
5 Event time 0 {1 ms} 65535 Cycle time
