Lenze EPM-T110 - Page 295

Index table
14
Appendix
14.2
l
14.2-5
EDSPM-TXXX-3.0-04/2004
Index ImportantPossible settingsName
SelectionLenze
I1408
h
Index is only a vailable in the modular
system
E 9.4-3
1 COB-ID used by
RxPDO 9
1344 385 {1} 2047 Defining the individual identifie rs for
process da ta object 9
2 Transmisson type 255 0 {1} 255 Defining the transmission mode
0 Sync-controlled receive The input data are a ccepted on sync
telegram transmission.
1 ... 240 N-sync-controlled reception The input data are accepted after
transmission of the set number (1 ... 240)
of sync telegrams.
255 Event-controlled reception Every received value is accepted
I1409
h
Index is only a vailable in the modular
system
E 9.4-3
1 COB-ID used by
RxPDO 10
1665 385 {1} 2047 Defining the individual identifie rs for
process da ta object 10
2 Transmission mode 255 0 {1} 255 Defining the transmission mode
0 Sync-controlled reception The input data are accepted on sync
telegram transmission.
1 ... 240 N-sync-controlled reception The input data are accepted after
transmission of the set number (1 ... 240)
of sync telegrams.
255 Event-controlled reception Every received value is accepted
I1600
h
*
Mapping parameters for receive PDOs
0 Number of mapped
RxPDO1
0 {1} 255 8 bit value
1 1st mapped object 00000000
h
{1} FFFFFFFF
h
32 bit value
2 2nd mapped object 00000000
h
{1} FFFFFFFF
h
32 bit value
3 3rd ma pped object 00000000
h
{1} FFFFFFFF
h
32 bit value
4 4th mapped object 00000000
h
{1} FFFFFFFF
h
32 bit value
5 5th mapped object 00000000
h
{1} FFFFFFFF
h
32 bit value
6 6th mapped object 00000000
h
{1} FFFFFFFF
h
32 bit value
7 7th mapped object 00000000
h
{1} FFFFFFFF
h
32 bit value
8 8th mapped object 00000000
h
{1} FFFFFFFF
h
32 bit value
I1800
h
Index is avail a ble in the modular and
compact system
E 9.4-3
1 COB-ID used by
TxPDO 1
767 385 {1} 2047 Defining the individual identifie rs for
process da ta object 1
2 Transmission mode 255 0 {1} 255 Defining the transmission mode
1 Sync-controlled transmission The output data are accepted on sync
telegram transmission.
2 ... 240 n-sync-controlled transmission The output data are a ccepted after
transmission of the set number (1 ... 240)
of sync telegrams.
254 Time-controlled transmission Only if a cycle time is set in I180x
h
,
subindex 5
255 Event-controlled transmission
255 Event-controlled transmission with cyclic
overlapping
Only if a cycle time is set in I180x
h
,
subindex 5
