4×analog input / output
5
The modular system
5.12
l
5.12-3
EDSPM-TXXX-3.0-04/2004
Type
4×analog input / output
Voltage supply DC 5 V / 100 mA (via backplane bus)
Extern al voltage supply DC 24 V / 110 mA (DC 20.4 ... 28.8 V)
Short-circuit current 30 mA
Connectable cable cross-section ≤ 2.5 mm
2
(≥ AWG 14)
Analog inputs
Number 2
Input area
Voltage DC 0 ... +10 V
DC -10 ... +10 V
DC +1 ... +5 V
Information on tolerances
c
a
n
b
e
f
o
u
n
d
i
n
t
h
e
c
h
a
p
t
e
r
Current 0 ... +20 mA
-20 ... +20 mA
+4 ... +20 mA
can be
f
ound in
t
he chap
t
er
”Parameter setting”
Conversion rate [Hz] 3.7 7.5 15 30 60 123 168 202
Processing time per channel [ms] 290 150 84 54 36 28 26 26
Resolution [Bit] 16 16 16 16 15 14 12 10
Electrical isolation from backplane bus Yes, via optocouplers
Analog outputs
Number 2
Analog-to-digital converter 12 bits
Output ranges
(Tolerances refer to the upper limit of effective
range)
Voltage DC0...+10V(±0.4%)
DC-10...+10V(±0.2%)
DC +1 ... +5 V (±0.6 %)
Current 0 ... +20 mA (±0.6 %)
-20 ... +20 mA (±0.3 %)
+4 ... +20 mA (±0.8 %)
Actuator input resistor
Voltage range min. 500 Ω
Current range max. 500 Ω
Delay time 10 ms
Electrical isolation from backplane bus Yes, via optocouplers
Communication
Input data 4 bytes (one word per channel)
Output data 4bytes
Parameter data 12 bytes
Diagnostic data 12 bytes
Dimensions
Width 25.4 mm
Height 76.0 mm
Depth 76.0 mm
Weight 100 g
Order number EPM-T330
Technical data
